Overview
The DJI Zenmuse V1 is a high-power aerial speaker payload for the DJI Matrice 350 RTK and Matrice 400 platforms. Delivering up to 129 dB sound pressure at 1 metre with an effective broadcast range of up to 700 metres, the V1 is designed for public address, emergency communication, crowd management, and search and rescue operations where clear voice projection from altitude is essential.
The V1 supports multiple broadcast modes including text-to-speech (TTS) in multiple languages, pre-recorded file playback, and record-and-broadcast. Its single-axis gimbal stabilisation keeps the speaker directed at the target area during flight, and its 30 W rated output ensures audible communication even in noisy environments or at extended distances.
With IP54 weather protection and an operating temperature range of -20°C to 50°C, the V1 is ready for field deployment in demanding conditions. It mounts via DJI SKYPORT and can be paired with camera payloads on the M350 RTK's dual-gimbal system for combined surveillance and communication operations.
| Specification | Details |
|---|---|
| Weight | 690 ±10 g |
| Dimensions | 134 × 119 × 140 mm |
| Rated Power | 30 W |
| Max Sound Pressure | 129 dB @ 1 m (Matrice 400), 127 dB @ 1 m (M350 RTK) |
| Effective Broadcast Distance | 700 m (Matrice 400), 500 m (M350 RTK) |
| Audio Bandwidth | 800 Hz to 8 kHz |
| Supported Formats | MP3, AAC, WAV |
| Modes | Text-to-speech, record & broadcast, file broadcast |
| Gimbal Stabilisation | Single-axis (tilt) |
| Tilt Range | -125° to +25° |
| IP Rating | IP54 |
| Operating Temperature | -20°C to 50°C |
| Compatible Aircraft | Matrice 400, Matrice 350 RTK, Matrice 300 RTK |
