Overview
The DJI Zenmuse S1 is a gimbal-stabilised spotlight payload for the DJI Matrice 350 RTK, designed to illuminate targets during nighttime and low-visibility operations. With a powerful, focusable beam, the S1 transforms the M350 RTK into a highly capable night operations platform when paired with camera payloads like the Zenmuse V1 or H30T on a dual-gimbal configuration.
The S1 features adjustable beam width and intensity, providing targeted illumination for search and rescue missions, law enforcement pursuits, nighttime infrastructure inspection, and emergency scene lighting. Its 3-axis gimbal stabilisation ensures the beam stays locked on target during flight, and smart tracking integration allows the spotlight to automatically follow moving subjects.
Purpose-built for the demanding conditions of nighttime field operations, the S1 is IP55-rated and operates across a wide temperature range. It mounts to any of the M350 RTK's gimbal positions, and when used on the upward or secondary gimbal alongside a camera payload, operators can independently control both the camera and spotlight for maximum operational flexibility.
| Specification | Details |
|---|---|
| Weight | 760 ±10 g |
| Dimensions | 125 × 152 × 171 mm |
| Rated Power | 120 W (Matrice 400), 68 W (M350 RTK / M300 RTK) |
| Max Illuminance | 40 lux @ 100 m (M400), 35 lux @ 100 m (M350 RTK) |
| Effective Illumination Distance | 500 m |
| Beam Angle | 15° (low beam / both on), 4° (high beam) |
| Modes | Low Beam, High Beam, Both On, Strobe (5 Hz) |
| Gimbal Stabilisation | 3-axis (tilt, roll, pan) |
| Tilt Range | -120° to +60° |
| IP Rating | IP54 |
| Operating Temperature | -20°C to 40°C |
| Compatible Aircraft | Matrice 400, Matrice 350 RTK, Matrice 300 RTK |
