Overview
The DJI Zenmuse P1 is a full-frame photogrammetry camera designed for the DJI Matrice 350 RTK (and previously M300 RTK), delivering the highest resolution aerial imaging in DJI's enterprise payload lineup. With a 45 MP full-frame CMOS sensor and mechanical shutter capable of capturing images at intervals as short as 0.7 seconds, the P1 is purpose-built for high-precision photogrammetric mapping, topographic surveys, and large-scale 3D reconstruction.
The P1 supports three interchangeable DJI DL-mount lenses — 24 mm, 35 mm, and 50 mm — giving surveyors flexibility to optimise ground sample distance and coverage area for each project. At 100 m altitude with the 35 mm lens, the P1 achieves a ground sample distance (GSD) of approximately 2.0 cm/pixel, enabling detailed mapping of construction sites, quarries, mining operations, and urban environments.
When combined with the M350 RTK's centimetre-level RTK positioning, the P1 achieves absolute accuracy of 3 cm horizontal and 5 cm vertical without ground control points — dramatically reducing survey time and cost. It integrates with DJI's Smart Oblique Capture mode for efficient 3D city modelling, and post-processing is handled in DJI Terra for orthomosaics, DSMs, 3D mesh models, and point clouds.
| Specification | Details |
|---|---|
| Weight | Approx. 800 g (with 35 mm lens) |
| Sensor | Full-frame (35.9 × 24 mm) CMOS |
| Effective Pixels | 45 MP (8192 × 5460) |
| Shutter | Mechanical shutter, min interval 0.7 s |
| ISO Range | 100-25600 |
| Compatible Lenses | DJI DL 24 mm f/2.8, 35 mm f/2.8, 50 mm f/2.8 |
| GSD (@ 100 m, 35 mm lens) | Approx. 2.0 cm/pixel |
| Photo Format | JPEG / DNG (RAW) |
| Smart Oblique Capture | Supported (3 lens angles per pass) |
| Gimbal Stabilisation | 3-axis (tilt, roll, pan) |
| Stabilisation Range | Tilt: -120° to +30°, Pan: ±320° |
| Operating Temperature | -20°C to 50°C |
| Compatible Aircraft | DJI Matrice 350 RTK, DJI Matrice 300 RTK |
